Coyote C-Series 34-inch Built-In 3-Burner Gas Grill

Coyote-C-Series-34-inch-2-Burner-Built-In-Gas-Grill-C1C34-LP-Closed1

Coyote C-Series 34-inch Built-In 3-Burner Gas GrillAOK_Logo_Quick-sm20-Burger

Coyotes 34-inch  3 burner built-in gas grill features 18 gauge 304 stainless steel construction with a double-lined cooking lid and continuously hand-welded fire box with seamless edges. Under the hood Coyote features Stainless Steel sizzle plates that control flare ups and heat evenly across the 616 square inch cooking area. The 34 inch grill has three, cast stainless steel Coyote Infinity Burners which deliver 20,000 BTUs for up to 60,000 BTUs of total cooking power. The ignition is easy to use, push and turn flame throw system while the internal halogen grill lights will keep you grilling into the night.

Features for:  COY-C1C34LP  COY-C1C34NGCoyote-IMG_6793

  • Three high performance cast stainless steel Coyote Infinity Burners
  • 750 square inches of cooking surface
  • Seamless welded stainless steel grill box with polished edges
  • Heat control grids distribute heat evenly across grilling surface
  • Push and turn ignition delivers a safe, reliable start
  • Interior halogen grill lights lets you cook into the night
  • Cutout Dimensions 31″W x 10 1/4″H x 20 1/2″D
  • Overall Dimensions 34″W x 23″H x 25 1/2″D

Click For Coyote-C1C34-C1C36-C1SandL36-C1S42-Manual

Click For  Coyote-C1C34-Spec-Sheet

Brands

Coyote

Combustable Setback

TO NON-COMBUSTIBLE CONSTRUCTION: For non-combustible material, Coyote grills can be placed directly on, or adjacent to the non-combustible material. The hood on a Coyote grill pivots mainly on the body. If you have a wall or partition behind the unit that would block ventilation, then a minimum of 7″ clearance from the back of the grill to the wall is needed for the purpose of ventilation. If you do not have a wall or partition blocking the ventilation of the unit, then you only need an extra 2″ behind the unit for the hood to open fully. If you wish to use the rotisserie option, you will want to make sure that you leave adequate space (at least 6″) on each side of the grill so that the motor and rotisserie spit handle will have room on the counter, as these extend past the overall dimensions of the grill body.
CLEARANCE TO COMBUSTIBLE CONSTRUCTION: For combustible construction, you must have at least 24″ clearance to any combustible material (in any direction) for a Coyote Warranty to be upheld and for the safety of the homeowner. You can NOT locate the grill under any combustible material without an approved ventilation system directly located above the unit.
INSULATED JACKETS AND COMBUSTIBLE CONSTRUCTION: If you must use combustible material to build your grill island AND you are going to be within 24″ of the grill with this combustible material, then you must use the appropriate Coyote Insulated Jacket. The insulated jacket will act as a barrier to protect your grill island from the heat and fire of your Coyote grill. If an insulated jacket is not used in a combustible material island, the warranty on the Coyote grill will be voided immediately and safety can not be ensured.

Electrical Requirements

Needs 115V GFCI Under Grill

Sizes

30-34″

Burner Information

3 ea 20,000 BTU Cast Stainless Steel Burners

Ignition Type

Piezo Ignition- No Power Needed – Similar to a Bic Lighter. Very Reliable System

Grilling Area

Cooking Grid Dimensions 32 X 17 1/4 Inches
Main Grilling Area 616 Sq. Inches
Warming Rack Area 164 Sq. Inches
Total Grilling Area 780 Sq. Inches

Dimensions

Cutout Dimensions 31″W x 10 1/4″H x 20 1/2″D
Overall Dimensions 34″W x 23″H x 25 1/2″D

Warranty

Coyote Outdoor warrants that each product will be free from defects in workmanship and materials on the stainless steel frame/housing and stainless steel burners for the lifetime of the original purchaser. They also warrant the cooking grids for five (5) years, the flavorizer bars and electric/plastic components for two (2) years, and the ignition systems/valves for one (1) year.
